Below are the project on Liv for 2019. We view 2019 projects as projects that needs to be completed before ÅFOR 2019 and our vacation in July.
Completed 2018 / 2019
- New septic hoes for toilet and septic tank
- New pump for toilet
- Rewiring of all electricity (Skyllermark cables and Blue Sea bus bars)
- Fuses or circuit breakers on all loads and chargers (ANL fuses and circuit breakers)
- Main fuse and main remote switch (T-Fuse and ML-series Remote switch)
- Under voltage protection (Battery Brain Type I)
- 8 x LiFeYPO4 Winston 160Ah wide cells in a 2P4S battery for 320Ah @ 12V battery
- New battery monitor (Victron BMV-712)
- MPPT solar panel regulator (Victron SmartSolar MPPT 75/15)
- Charger/inverter combo with Digital Multi Control (Victron MultiPlus 12/1200/50)
- Four additional folding pad-eyes as tethers anchors for crew and two additional for helmsman
- New water tank *
- New cold and hot fresh water hoes *
- New diesel hoes *
- New coolant hoes for engine and heater *
- Added isolation for the fridge/icebox and move compressor
- Smal gelcoat damage from stern anchor
- Stern protector plate for stern anchor
- Spinnaker boom holders and clutches for Furlex line and Gennaker resealed *
- All deck to hull bolts tightened *
- Refurbish gelcoat on hull
- Bow platform removed
- Cutter stay pad-eye on deck with reinforcements on and below deck
- Shelf / mount for bow windlass in anchor box
- Shelf / mount for two 5 kg LPG bottles in anchor box
- Divider in anchor box for anchor rode
- Repainted gel coat in anchor box
- Replaced LPG hoes
- Fastenings for 5kg LPG bottles in anchor box
- Removed bow platform and installed new bow anchor roller
- Bow windlass (Lewmar HX1)
- Cover for table during racing
- Scrape, sand and remove old antifouling (planned 2020)
- Three additional coats of epoxi on hull (planned 2020)
- Upgraded network from SeaTalk1 to SeaTalkNG (planned 2020)
- Replaced speed and temperature transducer (planned 2020)
- Added ITC-5 for conversion of transducer data to SeaTalkNG / NMEA 2000 (planned 2020)
- New Raymarine Evolution autopilot, old kept as spare (planned 2020)
- World Sailing Personal Survival training (Jonas) (planned 2020)
- World Sailing Personal Survival training (Sanna) (planned 2020)
- New rubber seal for S-drive and lower seal rings (planned 2020) *
- New vacuum valve for engine (planned 2020)
- New alternator and alternator regulator (planned 2020)
- Modern anchor and steel rode (Spade S100 with 60 m steel rode)
* Completed by Gustavsbergs Marincenter
Planned but did not have time to complete
- Improve emergency steering
- Cutterstay and new halyard for cutterstay
- Stom jib for cutter stay
- Bunknets on all beds (completed on three of four beds)
For some reason more and more items are added to the list…
